Walls

• Wall panels consist of 40 mm sandwich panels with EPS insulation (16 kg/m³ density)
• Both inner and outer surfaces are covered with 0.30 mm thick steel sheets
• External surfaces are protected with removable nylon coating during transport and installation
• Model-based exterior options:
  • PrimeCity: RAL 9002 white
  • AntraCity: RAL 7016 anthracite grey
  • SafranCity: RAL 9002 white + PVC wood cladding (lambris)

Chassis

• Manufactured from custom-formed galvanized steel profiles
• Designed specifically according to unit dimensions
• Includes integrated forklift pockets for easy transportation and handling

Roof

• Constructed with a custom-shaped galvanized steel frame
• Insulated with 50 mm polyurethane (PU) panels (40 kg/m³ density)
• Integrated rainwater drainage system:
  • Water is directed to gutters along roof edges
  • Discharged through vertical corner steel elements
• Prevents water accumulation and ensures long-term durability

Floor

• Base layer: 14 mm fully water-resistant fibercement board on steel chassis
• Top layer: 2 mm non-slip PVC flooring
• Designed for intensive use, hygiene, and easy maintenance

Door

• 40 mm insulated steel door with EPS insulation (16 kg/m³ density)
• Lockable from both inside and outside for user privacy and security
• Equipped with stainless steel door handle
• Designed for durability in intensive outdoor use

Ventilation

• 150 mm diameter ventilation fan is standard in all units
• Ensures continuous air circulation and moisture control
• Supports a hygienic and odor-free interior environment

Plumbing & Drainage System

• Clean water installation using high-quality PPRC piping system
• Wastewater system with PVC drainage pipes and optimized slope
• All systems are pre-installed and ready for external connection (plug & play)
• Boiler connections (water & electrical) are pre-prepared

Electrical Installation

• Fully pre-installed electrical system
• Equipped with RCD (Residual Current Device) and 16A circuit breaker
• All components are IP-protected (switches, sockets, lighting)
• Ready for direct connection to external power supply

Key Advantages

• Plug & play installation – no complex setup required
• Durable structure for long-term outdoor use
• Hygienic and easy-to-clean materials
• Designed specifically for camping, caravan, and glamping environments
